Quantum Fog
0.9.3
|
Public Member Functions | |
| def | __init__ (self, states_df, score_type, max_num_mtries, ess=1.0, verbose=False, vtx_to_states=None) |
| def | climb (self) |
| def | do_move (self, move, score_change, do_finish=True) |
| def | refresh_nx_graph (self) |
| def | would_create_cycle (self, move) |
| def | move_approved (self, move) |
| def | finish_do_move (self, move) |
| def | restart (self, mtry_num) |
| def | cache_this (self, move, score_change) |
| def | empty_cache (self) |
 Public Member Functions inherited from learning.NetStrucLner.NetStrucLner | |
| def | __init__ (self, is_quantum, states_df, vtx_to_states=None) |
| def | fill_bnet_with_parents (self, vtx_to_parents) |
Static Public Member Functions | |
| def | do_move_vtx_to_parents (move, vtx_to_parents, reversal=False) |
| def | do_move_nx_graph (move, nx_graph, reversal=False) |
| def | HC_lner_test (LnerClass, verbose=False) |
| Static Public Member Functions inherited from learning.NetStrucLner.NetStrucLner | |
| def | learn_nd_state_names (bnet, states_df) |
| def | import_nd_state_names (bnet, vtx_to_states) |
| def | int_sts_detector (sub_states_df) |
Public Attributes | |
| max_num_mtries | |
| score_type | |
| verbose | |
| vertices | |
| vtx_to_parents | |
| scorer | |
| nx_graph | |
| Public Attributes inherited from learning.NetStrucLner.NetStrucLner | |
| is_quantum | |
| bnet | |
| states_df | |
| ord_nodes | |
The HiilClimbingLner( Hill Climbing Learner ) class learns the structure
of a bnet using a greedy strategy, meaning it goes for the highest short
term gain without caring that that may not be in its long term interest,
as it may lead it to a local rather than the global maximum.
Each 'move' consists of either adding, deleting or reversing the
direction of an arrow. Each move is given a score. Score keeping is done
by an object of a separate class called NetStrucScorer. A 'try' or
'mtry' (move try) is a set of candidate moves. Only the highest scoring
move of a try is actually performed.
Classes that inherit from this one wil have the prefix HC_ for easy
identification and so that they stay together in an alphabetical listing.
References
----------
1. Nicholas Cullen neuroBN at github
Attributes
----------
is_quantum : bool
True for quantum bnets and False for classical bnets
bnet : BayesNet
a BayesNet in which we store what is learned
states_df : pandas.DataFrame
a Pandas DataFrame with training data. column = node and row =
sample. Each row/sample gives the state of the col/node
ord_nodes : list[DirectedNode]
a list of DirectedNode's named and in the same order as the column
labels of self.states_df.
max_num_mtries : int
maximum number of move tries
nx_graph : networkx.DiGraph
a networkx directed graph used to store arrows
score_type : str
score type, either 'LL', 'BIC, 'AIC', 'BDEU' or 'K2'
scorer : NetStrucScorer
object of NetStrucScorer class that keeps a running record of scores
verbose : bool
True for this prints a running commentary to console
vertices : list[str]
list of vertices (node names). Same as states_df.columns
vtx_to_parents : dict[str, list[str]]
dictionary mapping each vertex to a list of its parents's names | def learning.HillClimbingLner.HillClimbingLner.__init__ | ( | self, | |
| states_df, | |||
| score_type, | |||
| max_num_mtries, | |||
ess = 1.0, |
|||
verbose = False, |
|||
vtx_to_states = None |
|||
| ) |
Constructor
Parameters
----------
states_df : pandas.core.frame.DataFrame
score_type : str
max_num_mtries : int
ess : float
Equivalent Sample Size, a parameter in BDEU scorer. Fudge factor
that is supposed to grow as the amount of prior knowledge grows.
verbose : bool
vtx_to_states : dict[str, list[str]]
A dictionary mapping each node name to a list of its state names.
This information will be stored in self.bnet. If
vtx_to_states=None, constructor will learn vtx_to_states
from states_df
Returns
-------
None
| def learning.HillClimbingLner.HillClimbingLner.cache_this | ( | self, | |
| move, | |||
| score_change | |||
| ) |
This is a hook function that allows subclasses of this class to store in a list every move and its score change that was considered (whether it was the best move of the try or not) for the current try. Parameters ---------- move : tuple[str, str, str] score_change : tuple[float, float, float] Returns ------- None
| def learning.HillClimbingLner.HillClimbingLner.climb | ( | self | ) |
This is the main engine of the whole class. Most of the other functions of this class are called inside this function. Returns ------- None
| def learning.HillClimbingLner.HillClimbingLner.do_move | ( | self, | |
| move, | |||
| score_change, | |||
do_finish = True |
|||
| ) |
Once the move has been approved/vetted, it is performed by this
method.
Parameters
----------
move : tuple[str, str, str]
a move is a 3-tuple (beg_vtx, end_vtx, action) describing an
arrow beg_vtx->end_vtx that will be either added, deleted or
reversed, depending on whether action = 'add', 'del', or 'rev'.
score_change : tuple[float, float, float]
score_change is a 3-tuple (beg_vtx_score_ch, end_vtx_score_ch,
tot_score_ch). beg_score_ch is the score change of the beg_vtx
of move, end_score_ch is the score change of the end_vtx of
move. This is possible because all score functions can be
evaluated for a single vtx. tot_score_ch is the sum of
beg_score_ch and end_score_ch minus a positive penalty that
increases with the size of the network.
do_finish : bool
True if you want to finish off this function with a call to
finish_do_move().
Returns
-------
None
|
static |
Applies move or its reversal to a networkx dag.
Parameters
----------
move : tuple[str, str, str]
nx_graph : networkx.DiGraph
reversal : bool
If True, the function applies reversal of move to nx_graph
Returns
-------
None
|
static |
Applies a move or its reversal to a vtx_to_parents
Parameters
----------
move : tuple[str, str, str]
vtx_to_parents : dict[str, list[str]]
dictionary mapping each vertex to a list of its parents's names
reversal : bool
If True, the function applies reversal of move to vtx_to_parents
Returns
-------
None
| def learning.HillClimbingLner.HillClimbingLner.empty_cache | ( | self | ) |
This is a hook function that allows subclasses of this class to clear its cached list of moves before starting the next try. Returns ------- None
| def learning.HillClimbingLner.HillClimbingLner.finish_do_move | ( | self, | |
| move | |||
| ) |
This is a hook function that allows subclasses of this class to do some additional processing before the do_move() function is concluded. Parameters ---------- move : tuple[str, str, str] Returns ------- None
|
static |
This static method gives a simple example that we use to test
HillClimbingLner and its subclasses (those starting with HC_). The
method takes in as input training data generated from 2 graphs (the
classical versions of wetgrass and earthquake), and it outputs a
drawing of the learned structure for 2 scoring functions (
BIC-frequentist and BDEU-bayesian)
Parameters
----------
LnerClass : HillClimbingLner or subclass
This is either HillClimbingLner without quotes or the name of a
subclass of that class.
verbose : bool
Returns
-------
| def learning.HillClimbingLner.HillClimbingLner.move_approved | ( | self, | |
| move | |||
| ) |
This is a hook function that allows subclasses of this class to impose more stringent requirements on a move before it is approved, beyond the usual requirement that the move not create a cycle. The function returns a bool, its decision. Parameters ---------- move : tuple[str, str, str] Returns ------- bool
| def learning.HillClimbingLner.HillClimbingLner.refresh_nx_graph | ( | self | ) |
This function clears self.nx_graph and refills it with info in self.vtx_to_parents. Returns ------- None
| def learning.HillClimbingLner.HillClimbingLner.restart | ( | self, | |
| mtry_num | |||
| ) |
This is a hook function that allows subclasses of this class to
restart the trying process when the last try yielded no moves with
positive score change. mtry_num is passed in. (restart_approved,
mtry_num) are returned, where restart_approved is a boolean
signaling approval and mtry_num is an int, usually either the
inputted mtry_num or zero.
Parameters
----------
mtry_num : int
move try num is the number of the current try
Returns
-------
bool, int
| def learning.HillClimbingLner.HillClimbingLner.would_create_cycle | ( | self, | |
| move | |||
| ) |
This function performs the move 'move' on self.nx_graph and then tests to see if the new graph has cycles. It communicates the result of the tests in the bool output. It restores nx_graph to its original state after the testing for cycles is concluded. Parameters ---------- move : tuple[str, str, str] Returns ------- bool
